HW-Labs GT Stealth serien er den første af den nye generation af vandkølingsradiatorer som giver kompromisløs ydelse i Stealth stille systemer. GT Stealth er bygget over Black Ice designet, men det er blevet redesignet så det maksimerer ydelsen til Black Ice Xtreme niveau ved lownoise brug, selvom den er halvt så tyk.
Der hvor mange producenter har sænket antallet af finner i radiatoren, har HW-Labs valgt at gå i en helt anden retning.
De har gjort finnerne tyndere og mindre i en Dual-Core struktur, hvilket har tilladt dem at øget antallet til 30 FPI (fins per inch), samtidig med at luftmodstanden i radiatoren er sænket. De mange små finner giver en masse turbulens i luften, og som med vand, så optager luften meget bedre varme i turbulent form.
Dette gør at du får en højtydende radiator i et ultra kompakt design.
Designet er, som navnet antyder, inspireret af det super højteknologiske kampfly F-117A Nighthawk, som var det første operative fly med stealth teknologi.
Linierne er skarpe, vinkler over 90 grader og i skudsikker kvalitet.
HW-Labs GTS er uden tvivl den mest avancerede vandkølingsradiator til dato.
Producentens beskrivelse:
The Black Ice® GT Stealth 140 is the first true next generation PC radiator designed for uncompromising performance and stealth operation. The GTS140 boasts of a radically redesigned Black Ice® core technology that maximizes heat transfer efficiency for the new 140mm fan form factor.
Specifikationer:
* Two-pass U-flow Tank configuration.
* Custom MaxFin™ 25 micron Copper Splitter Fin Configuration utilizing 45% thinner fin material yielding up to 50% less pressure drop even with twice the fin density.
* Unique fin configuration eliminates intra-louver accumulation of dust particles for trouble free operation.
* Unprecedented Ultra-high 30 FPI (Fins Per Inch) fin density providing dramatically increased heat transfer surface area.
* Custom low-profile 19.0 x 1.2mm MaxFlow™ tubes with 15% more waterside surface area and 60% frontal area reduction for superior low air-resistance aerodynamics and lower internal flow requirements.
* Yields up to 35% more heat exchange capacity than the Black Ice® Pro in both Stealth or Performance modes.
* Achieves Black Ice® Xtreme level performance in stealth mode (low-noise/low-airflow conditions).
* First computer radiator configured and optimized for 140mm fans.
* M4 Threaded Screw Holes for easier mounting and greater adaptability.
* Now standard G 1/4" female threaded fittings.
* Full high-temper brass structural construction for weight reduction and superior corrosion resistance.
* Uses 100% Non-corrosive water-soluble fluxing process.
* Lead-free construction for environmental protection and RoHS compliance.
* Full electrostatic polyurethane painting finish for uniform coating with high temperature curing for increased finish durability.
* Renowned Black Ice® quality.
* Patent Pending Design.
Bemærk: Produktet leveres uden fittings.
Fittings med
¼" BSPP (G1/4) gevind passer til dette produkt.
